Laser coatings

For highly reflective mirrors, on the other hand, only dielectric coatings are used. These transmit the non-reflected part and can therefore achieve very low absorption values. These coating systems are optimized for one wavelength or one laser and thus achieve reflection values of up to 99.9%.

CO2 laser coatings

The coatings for CO2 lasers are designed and manufactured for the highest demands in industrial environments.

Total reflector at 10.6 µm

This coating is designed for high-power applications and external optics for laser cutting or laser marking.

R > 99.9 % @ 10.6 µm and AOI 45° (s-pole)

R > 99.7 % @ 10.6 µm and AOI 45° (p-pole)

R > 45.0 % @ 0.632 µm and AOI 45° (r-pol)

Datasheet

Total reflector at 10.6 µm and 632 nm

A total reflector coating for 632 nm is designed for high-power applications in which additional high reflection is required for a pilot laser due to multiple reflections.

R > 99.8 % @ 10.6 µm and AOI 45° (s-pole)

R > 99.6 % @ 10.6 µm and AOI 45° (p-pole)

R > 75.0 % @ 0.632 µm and AOI 45° (r-pole)

Datasheet

Total Reflector Cavity at 10.6 µm

This coating is designed for high-power CO2 laser cavities. It is particularly stable against the high UV radiation in the resonator and has particularly low absorption.

R > 99.8 % @ 10.6 µm and AOI 0°

Datasheet

YAG Laser Coatings

Enhanced Gold

Based on a gold layer, an Enhanced Gold coating shines through dielectric multilayers with increased reflection.

R > 99.6 % @ 1.064 µm and AOI 45° (s-pole)

R > 99.4 % @ 1.064 µm and AOI 45° (p-pol)

All-dielectric

This coating is designed for high-power applications and consists of a dilelectric multilayer.

R > 99.9 % @ 1.064 µm and AOI 45° (s-pole)

R > 99.8 % @ 1.064 µm and AOI 45° (p-pole)

Fiber Laser Coatings

Enhanced Gold

Based on a gold layer, an additional dielectric multilayer is added to an Enhanced Gold coating.

R > 99.6 % @ 1.064 µm and AOI 45° (s-pole)

R > 99.4 % @ 1.064 µm and AOI 45° (p-pole)

All-dielectric

This coating is designed for high-power fiber laser applications and consists of a dilelectric multilayer.

R > 99.9 % @ 930-980 nm and AOI 45° (s-pole)

R > 99.8 % @ 930-980 nm and AOI 45° (p-pole)
