Silicon

Silicon

Silicon lenses are used for the manufacture of long-life IR systems. They are suitable for focusing IR radiation. They are therefore often used in camera lenses.

Nutzen Sie die Vorteile der Silizium Optiken von Pleiger Laseroptik:

Silicon lenses are anti-reflective coated with a PVD coating to achieve optimum transmission. Lenses made of silicon are used in NIR systems in the 2-8 µm range.

  • Low chromatic aberration
  • High mechanical stability
  • Suitable for IR imaging
  • Application range 2-8 µm
  • Customized production
  • Maximum experience and competent expertise
  • Wide range of applications
Materialeigenschaften von Silicon

Silicon -  ...und wofür es gut ist

Anlesertext zum Material

Praxisbezug des Substrats bzw. der Linsen

Qualitätsmerkmale

Erläuterungstext zu den Qualitätsmerkmalen

Silicon

Material properties

Density:

2.33

Young‘s modulus:

130.0

Knopp Hardness:

1,150

Poisson Ratio:

0.24

Heat capacity:

703

Thermal conductivity:

163.00

Transmission range:

1,2 - 15 (2 mm Si)
